Selection Arborist Chainsaws

MS 150 TC-E

Extremely light 1.0 kW arborist chainsaw

General

MS 150 TC-E
Enlarge
More pictures

Ideal for cutting back trees, professional pruning, limited crown reduction and working from a cherry picker. This lightweight champion of STIHL arborist saws delivers high cutting performance for its class with fine cut surfaces and has a good power-to-weight ratio. With ErgoStart as standard.

Versions

Price

** Price on request from your STIHL Approved Dealer

The version(s) available in each country may differ from the above range and specifications; specific details may be subject to change without notice. Please ask your local STIHL Approved Dealer for further information.

Product variations

Technical data

MS 150 TC-E

Technical data

Displacement cm³ 23,6
Performance kW 1
Weight kg 1) 2,6
Power-to-weight ratio kg/kW 2,6
Chain pitch 1/4"P
Rollomatic E, cutting length cm 30
EPA Certified fuel consumption l/h 0,51
Oil tank volume cm3 150

1) Without fuel, without bar and chain

The version(s) available in each country may differ from the above range and specifications; specific details may be subject to change without notice. Please ask your local STIHL Approved Dealer for further information.

Features

MS 150 TC-E

Standard features

  • Advanced combustion technology Zoom
    Advanced combustion technology

    Four overflow channels swirl the fuel-air mix before ignition, allowing for optimum combustion and highly efficient performance. The result is lower fuel consumption and high torque across a broad rpm range.

  • STIHL anti-vibration system Zoom
    STIHL anti-vibration system

    Precisely calculated buffer zones minimise the transfer of engine and saw chain vibrations to the front and rear handles. The chainsaw therefore runs noticeably smoother. This allows the user to save their strength and work longer.

  • Tool free fuel caps Zoom
    Tool free fuel caps

    Special caps to open and close the tank cap quickly, easily and without tools.

  • Compensator Zoom
    Compensator

    This controller in the carburettor prevents the fuel-air mixture getting richer as the air filter becomes clogged. The correct quantity of fuel is delivered to the carburettor depending on the quantity of air passing through the air filter. This keeps the fuel/air ratio in the combustion mixture constant and hence also the engine power. The filter doesn't need to be cleaned until an appreciable drop in power occurs.

  • STIHL Ematic System Zoom
    STIHL Ematic System

    Compared to conventional bars without Ematic, the STIHL Ematic system reduces the consumption of chain lubricant by up to 50 %, depending on the type of wood and the cutting attachment used. This system comprises a STIHL Ematic or Ematic S guide bar, a STIHL Oilomatic saw chain and a variable-flow or reduced-flow oil pump. As a result, virtually every drop of chain lubricant is delivered to exactly the right spot.

  • Manual fuel pump (Purger) Zoom
    Manual fuel pump (Purger)

    STIHL chainsaws and pole pruners with manual fuel pumps allow improved starting with a reduced number of starting pulls. Pressing the primer fills the carburettor control chamber with fuel. This ensures that there is sufficient fuel present to create an ignitable air-fuel mix on starting, requiring significantly fewer starting pulls.

  • QuickStop Chain Brake Zoom
    QuickStop Chain Brake

    The chain brake on your STIHL chainsaw can be triggered automatically or manually. In both cases, the brake band encloses the clutch drum and prevents the chain starting to move even when the throttle trigger is squeezed. The chain brake is applied manually by pressing the front hand guard on your STIHL chainsaw forwards. It is activated automatically whenever a sufficiently strong kickback is encountered.

  • Side-mounted chain tensioning Zoom
    Side-mounted chain tensioning

    Side-mounted chain tensioning makes it easy to tension the chain safely.

  • STIHL ErgoStart (E)
    STIHL ErgoStart (E)

    A spring between the starter cord reel and crankshaft relieves the strain when starting, meaning that excessive pulling on the cord is no longer needed. The result is a convenient starting procedure with practically.

The version(s) available in each country may differ from the above range and specifications; specific details may be subject to change without notice. Please ask your local STIHL Approved Dealer for further information.

Dokumente

Gebrauchsanleitungen

STIHL MS 150 TC (GB) Download PDF, 1,9 MB
